SunCoast Diesel 4R70W/4R75W CATEGORY 2 REBUILD KIT - SC-4R70W-2

SC-4R70W-2
CATEGORY 1 4R70W/4R75W SUNCOAST REBUILD KIT
Please Call for Availability
844-623-7278

Description

Features and Benefits

  • Raybestos Clutch Module With GPZ Direct Clutch Pack® Module
  • Raybestos Upgraded Steel Clutch Module
  • Raybestos Upgraded Pro Series Overdrive Band
  • New Low/Reverse Band
  • New Molded Piston Kit
  • New Bushing Kit
  • New Thrust Washer Kit
  • New Filter
  • New Overhaul Kit
  • All Gaskets and Seals
  • New Torrington Thrust Bearing Kit
  • Updated Direct Drum Thrust Bearing
  • Spiral Retaining Ring Kit
  • New Front Pump Bushing
  • Heavy Duty Forward Sun Gear
  • Elevated Pressure Regulator Spring
  • New Torlon Check Balls
  • 2-3 Accumulator Piston
  • 1-2 Accumulator Kit
  • Tool to Install 1-2 Accumulator Kit
  • Heavy Duty Intermediate Shaft
  • Smart Tech Forward Clutch Drum
  • Sonnax Zip Kit
  • New Torque Converter

In this kit, we specifically upgrade several components in comparison to the Category 1 4R70W rebuild kit. These components include a new Heavy duty intermediate shaft, Smart Tech forward clutch drum, Sonnax Zip Kit, and a New Torque Converter.

The 4R70W

In 1962 Ford began working on a new type of automatic transmission that would emphasize fuel economy and drivability. The new transmission was built around the Ravigneaux Planetary Gearset of the "X" transmissions. Where many transmissions had a fourth gear added on as an afterthought, Ford's new transmission was designed with a fourth gear integrated into the gearset. Because it was based on the "X" transmissions, its gear ratios from 1-3 were the same with the fourth being 0.67:1. The transmission featured a split-torque application for third gear as well as a lockup in the torque converter. The XT-LOD was initially abandoned in 1966 but design began again in 1974 as a result of rising gas prices. The project was shelved with a design that lacked a damper in the torque converter but after the project was revisited a damper ultimately made its way into the final design. The transmission was introduced when Ford started to downsize its full-size line in 1979. Initially called XT-LOD (Extension Lock-Up Overdrive) its name was changed when revisited in 1974 to FIOD (Ford Integrated Overdrive) and then to its final name in 1979, the Ford AOD transmission.

A revised version of the AOD-E Transmission was released in 1993 with the Lincoln Mark VIII. Unlike the AOD-E, both 1st and 2nd gear ratios in the 4R70-W are numerically higher, giving the transmission a better mechanical advantage and in turn, better take-off acceleration, slightly lower fuel consumption, and designed for better gearset strength. On vehicles powered by the 5.4L V8, a stronger gearset is used than in normal duty 4R70Ws. In 1998, due to durability concerns, the intermediate one-way roller clutch was replaced with a mechanical diode providing extra holding capacity and longer service.

While there is some speculation that the 70 can be multiplied by 10 to indicate the ft-lb of torque this transmission is capable of handling including torque converter multiplication, (i.e. 700 ft-lb of torque), there is no reliable source indicating this. In fact, a Ford document stated that the 2003 "Expedition's 4R70W transmission is rated to handle up to 506 foot-pounds of torque, which provides a large performance cushion beyond the peak torque rating of Expedition's largest available engine." It is more plausible that the number indicates the torque handling capability in N-m, as 506lb-ft converts to 686 N-m which could be rounded to 700 N-m. The "70" may also refer to the transmission's torque capacity after torque converter multiplication which occurs at low rpm's when the torque converter is more "elastic". 4R70W indicates 4 gears, Rear wheel drive and Wider gear ratio compared to the AODE.

The Clutches

Raybestos Powertrain GPZ friction plates greatly increase transmission performance and durability. This state-of-the-art friction material far exceeds OE material to withstand high stress, high temperatures and repeated cycling. GPZ's outstanding performance. Raybestos Stage-1 Performance frictions are an affordable solution for performance applications that may not require the capacity of the Gen2 Blue Plate Special, but do require a friction plate that can handle the demands that a stock tan or high energy plate. benefits are perfect for heavy-duty vehicles and high-stress driving. Testing of GPZ revolutionary friction material shows that it outperforms OE materials by as much as 20%. Plus, its performance improves as the power increases.

Advantages

  • Enhanced Shift Feel
  • Withstands High Horsepower
  • Greater Torque Holding Capacity
  • Maintains Piston Travel
  • Optimum Performance
  • Higher Heat Resistance
  • Made in the USA

Bearing Kit

This kit contains a new Torrington thrust bearing kit. Replace thrust bearings should be a part of every rebuild. These have needle bearings that can be contaminated with debris from previous failures. This is a new complete Torrington thrust bearing kit.

Spiral Retaining Ring Kit

Vehicles equipped with 4R70W/4R75W and AOD/AODE transmissions often experience failure of the intermediate roller clutch or mechanical diode during high-rpm conditions.

This upgraded spiral retaining ring kit 76554RK incorporates a spiral snap ring that is staked to a locking ring to ensure ring contact with groove during high-rpm conditions, eliminating blowout. This works in roller clutch or mechanical diode applications.

  • Wrap-around design maintains contact with groove bottom
  • Locking ring prevents spiral retaining ring expansion during high RPM

Upgraded Pump Bushing

It can be difficult to establish the proper clearance between the converter hub and bushing in listed Ford units because aftermarket drop-in replacement bushings are not thick enough. Sonnax pump bushing 36002-01 is a finish-in-place front pump bushing.

  • Bushing is steel-backed bronze for better wear resistance
  • When installed, bushing allows .008" to .010" material removal for maintaining correct bushing-to-hub clearance

Heavy Duty Forward Sun Gear

Sonnax heavy duty forward sun gear 76612A-01 is a direct replacement for all 31-tooth sun gears used in 2.84/1.55 ratio gear sets. Manufactured from 9310 alloy steel, this gear is significantly tougher and stronger than OE or other aftermarket sun gears and is the perfect option for demanding applications. This is the same sun gear included with Sonnax Smart-Tech® direct drum and shaft kit 76656-01K that combines high-strength direct drum with integrated intermediate stub shaft.

  • Unique sun gear is precision-machined from 9310, heat-treated steel
  • Can be used with stock-size shaft and drums for medium-duty or budget builds

Elevated Pressure Regulator Spring

Ford Vehicles equipped with 4R70W and AODE units may suffer delayed engagements and burnt forward clutches due to low line pressure. This can be even more pronounced in heavy-duty or performance vehicles. Installing Sonnax elevated pressure main pressure regulator spring 76948-06 eliminates these concerns by raising base line pressure to securely engage clutches.

2-3 Accumulator Piston

Sonnax 76836A 2-3 accumulator piston is a direct OE replacement. The bonded rubber piston seals will prevent leakage between the piston O.D. and the case bore. This piston assembly is used in AOD-E and 4R70W transmissions.

  • Bonded rubber piston seals
  • Direct OE replacement

1-2 Accumulator Repair Kit

Common complaints in Ford AODE and 4R70 series transmissions are delayed Forward engagement and harsh 1-2 shifts caused by the 1-2 accumulator bore in the case being worn or scored. This wear results in the loss of 2nd clutch pressure and the need to replace the case. Sonnax 1-2 accumulator sleeve kit 76890-01K salvages expensive cases and restores the 1-2 shift.

  • Salvages expensive cases
  • Restores 1-2 shifts
  • Requires no machining of the case
  • Sonnax tool 76890-TL simplifies installation and ensures correct sleeve orientation
  • Drop-in Zip Valve™ parts install quickly and easily

Heavy Duty Intermediate Shaft

Intermediate stub shaft failure is a common problem in Ford AODE, 4R70W, 4R70E and 4R75W, 4R75E transmissions used in abusive applications or with increased power levels. Sonnax heavy duty intermediate stub shaft 76670A-01 is specially heat-treated, cryogenically processed and shot-peened for maximum strength and resistance to fracture, making it the strongest drop-in option for AODE/4R70W units.

  • Manufactured from 300M ultra-high-strength steel
  • Shot peened to prevent micro-cracking
  • Rolled splines for increased strength and durability

The Zip Kit

Sonnax Zip Kit AODE-4R75E-ZIP targets the root cause of multiple concerns by sealing critical circuit pressure losses in the valve body. The kit contains uniquely-designed parts to prevent the loss of pressures within the main line, solenoid regulator, converter clutch and overdrive servo circuits. The kit also contains components to address forward and intermediate clutch failure, overdrive servo failure, soft shifts, intermediate roller clutch/mechanical diode failure, and low clutch apply pressure. No separate special tools are required for installing these parts.

The Zip Kit quick guide provides clear and easy instructions on one sheet to get the unit sealed up and back on the road quickly. In addition to general rebuilding tips and technical information, the technical booklet included in this kit contains vacuum testing information and locations at other key areas of the valve body.

  • Drop-in Zip Valve parts install quickly and easily, no reaming or special tools required
  • Uniquely designed parts address root causes of valve body concerns by sealing critical pressure circuits
  • Detailed technical booklet included with in-depth rebuild and inspection tips for comprehensive valve body repair

Upgraded Forward Clutch Drum

A common failure of listed Ford transmissions is cracking of the forward drum at the snap ring groove. The manufacturing process of the OE snap ring groove creates high-stress points around the circumference of the drum. The drum is active in 1st, 2nd and 3rd gear ranges and suffers the most abuse on a forced 4-3 kick down when it reapplies at higher pressure.

The concurrent pressure from the forward clutch piston combined with the high stress at the snap ring groove causes the upper portion of the drum to split and separate at the groove. Depending on severity of crack, this can result in no forward engagement or slipping in 1st, 2nd and 3rd gear. The forged, one-piece construction of the Sonnax Smart-Tech forward clutch drum 76654-01K eliminates weakness at these stress points.

  • Increased groove depth for additional ring support
  • One-piece forged material provides increased strength and durability over the OE stamped drum
